Product Overview
The Monitor Audio WSS230 design brings with it our renowned C-CAM metal cone drivers, resulting in added sonic precision and detail.
Offering a step-up from the WSS130, this Super Slim in-wall model is one for projects where (even) more critical music reproduction is required.
FEATURES
- Super-slim depth 50 mm (2") – designed to fit in 2" stud walls or where space is restricted
- Designed for portrait or landscape installation – fits between standard 14" stud bays
- Elegant, slim profile only 385 x 140 mm wide
- Three, 3" bass/mid-range drivers featuring incremental technology and performance benefits – MMP II, C-CAM and dished C-CAM cones
- 25 mm C-CAM Gold Dome tweeter used on WSS130 and WSS230 models. WSS430 utilises MPD high frequency transducer from Platinum IC model and flagship Platinum II speaker range
- High quality crossover components – Selected and voiced for amazing sonic performance
- Magnetically attached ‘trim-less’ grille – discreet, reliable, and easy servicing
- Tri-Grip Dog leg fixings – reliable, robust, and quick to install
- Gold plated sprung push terminals – easy to connect and reliable
- Paintable grille – to complement and blend with décor
- WSS430 has rotating tweeter for optimum dispersion when used in landscape configuration
What You Get
- 1 x WSS230 In Wall Speaker
- 1 x White Grille
- 1 x Cut Out Template
- 1 x Instruction Manual
Specifications
- Frequency Response (-6 dB): 75 Hz – 30 kHz
- Sensitivity (1W@1M): 87 dB
- Nominal Impedance: 8 ohms
- Maximum SPL: 105.6 dBA
- Power Handling: 60 W Full Range, 100 W with crossover set to 100 Hz @ 12 dB/Octave
- Recommended Amplifier Requirements: 10 – 100 W
- Drive Unit Complement: 3 x 3" C-CAM cone bass-mid drivers, 1 x 25 mm (1") C-CAM Gold Dome tweeter
- Crossover Recommendation (using AVR/Processor): 100 Hz at a minimum of 12 dB/Octave (24 dB/Octave optimum)
- Overall Dimensions: 385 x 140.5 mm (15 x 5½")
- Overall Depth (Including Grille): 54.25 mm (2⅛")
- Cut-Out Dimensions: 346 x 101 mm (13½ x 4")
- Mounting Depth: 50 mm (2")
- Connection: Gold-plated sprung push terminals for bare wire connection up to 3 mm²
- Fixing Type: 6-position Tri-Grip dog-leg fixings
- Construction Material: Mineral-filled ABS plastic, RoHS2 compliant; painted steel grille
- Weight: 1.4 kg (3 lb 2 oz)
- Pre-Construction Bracket: WB3 Pre-Construction Bracket (Dark Blue)
- Sold As: Single unit
